JSON Implementation guide

Introduction

Welcome to the JSON Implementation Guide. Below you will find general guidelines for default JSON format DDS provides out of the box. If your company has chosen a custom format, this guide may still be of use in understanding the underlying data.

JSON

# Example of one JSON object per row
{"product_id".....}
{"product_id".....}
{"product_id".....}
{"product_id".....}
{"product_id".....}
# this is the non-flattend json for primary images
"primary_image": {
        "name": "Scotch-Brite_Light_Duty_Cleansing_Pad_98.png",
        "display_name": "primary_image",
        "mime_type": "image/png",
        "weight": 10,
        "uri":"https://media.distributordatasolutions.com/xlsx_3M_synd/2021q1/images/large/8ee6ad83816f3f3f79d30b109bf570283b4a4953-large.png",
      "sizes":{
         "thumb":{
            "length":"4983",
            "uri":"https://media.distributordatasolutions.com/xlsx_3M_synd/2021q1/images/thumbnails/8ee6ad83816f3f3f79d30b109bf570283b4a4953-thumb.png"
         },
         "small":{
            "length":"31752",
            "uri":"https://media.distributordatasolutions.com/xlsx_3M_synd/2021q1/images/small/8ee6ad83816f3f3f79d30b109bf570283b4a4953-small.png"
         },
         "medium":{
            "length":"128403",
            "uri":"https://media.distributordatasolutions.com/xlsx_3M_synd/2021q1/images/medium/8ee6ad83816f3f3f79d30b109bf570283b4a4953-medium.png"
         },
         "large":{
            "length":"545958",
            "uri":"https://media.distributordatasolutions.com/xlsx_3M_synd/2021q1/images/large/8ee6ad83816f3f3f79d30b109bf570283b4a4953-large.png"
         },
         "native":{
            "length":"3367671",
            "uri":"https://media.distributordatasolutions.com/xlsx_3M_synd/2021q1/images/native/8ee6ad83816f3f3f79d30b109bf570283b4a4953-native.png"
         }
        }
    }

Multi Part files

Our default JSON data is in multiple part files. There will be many files in the delivered directory. Filenames will follow the format part-{UUID with dashes}.json.

Multiple JSON Object per file

The most important thing to understand about the JSON format is that we provide one JSON object on each line of the files. Each JSON object represents a single product as described here: http://jsonlines.org/.

JSON NULL values

Null values are excluded in our JSON files fields. Any code you use to parse the json will need to handle the absence of a field you expect to be present. For example, not all manufacturers supply packaging dimensions.

Item Details

Item Details

{
    "product_id": 913512,
    "manufacturer_catalog_number": "141A-BS10",
    "upc": "611320791747",
    "name": "141A-BS10 - 141A MCS Mounting System Busbar Covers and Shrouds",
    "short_description": "MCS Single Pole Snap-On Bus Bar Cover",
    "long_description": "Individual Busbar Covers (for 10 mm Busbar), Priced per piece; must buy in multiples of 10",
    "alternate_images": [],
    "region_id": "GBR",
    "country_of_origin": "DE",
    "currency": "GBP",
    "discount_code": "B7",
    "family_code": "B141ABCVR",
    "list_price": 13,
    "manufacturer": {},
    "order_min": 10,
    "packages": [{}],
    "preferred_product": "X",
    "price_effective_date": "2017-08-27",
    "primary_image": {},
    "rohs_indicator": "COMPLIANT",
    "prop_65_message":"No",
    "tariff_code": "85472000",
    "height": "7.010",
    "height_uom": "CM",
    "length": "11.000",
    "length_uom": "CM",
    "width": "10.210",
    "width_uom": "CM",
    "primary_spec_sheet": { },
    "manufacturer_categories": [],
    "facets": [],
    "features": [],
    "specifications": [],
    "downloads": [],
    "videos": []
}
Field Name Data Type Description
distributor_product_id String Distributor unique identifier
product_id Integer DDS unique identifier
manufacturer_catalog_number String Uniquely Identifies the product within a manufacturer
upc String UPC (technically refers to UPC-A) consists of 12 numeric digits, that are uniquely assigned to each product. Can have leading Zeros
unspsc Integer The United Nations Standard Products and Services Code
name String Product name
short_description String Brief description of the product (will typically match the product name)
long_description String Longer description of the product
primary_image List of Image Objects Primary image
alternate_images List of Image Objects List of alternate images
region_id String Identifies which region the list price is associate with
country_of_origin String Country where the product was manufactured
currency String Currency of the list price
discount_code String Manufacturer's discount code
family_code String Identifies a product Group or Family. Defined by each individual manufacturer
list_price Decimal List price of the product for the specified region and currency
manufacturer Manufacturer Object Object detailing manfacturer, manufacturer logo and its parent, if applicable
order_min Integer Size of the minimum order as defined by the manufacturer
packages List of Package Objects List of different package size options
preferred_product String Manufacturer will identify a list products which are "preferred". An "X" signifies a preferred product
price_effective_date DateTime Data when a list price starts for a product
rohs_indicator String Restriction of Hazardous Substances Compliance
prop_65_message String Warning given for products sold in California
tariff_code String Tariff code
height Double Height of the product
height_uom String Abbreviation of the unit of measure for the height (standard or imperial based on the region id)
length Double Length of the product
length_uom String Abbreviation of the unit of measure for the length (standard or imperial based on the region id)
width Double Width of the product
width_uom String Abbreviation of the unit of measure for the length (standard or imperial based on the region id)
primary_spec_sheet File Object Primary spec sheet details. This file is also contained in the 'downloads' section. It is split out here as well for easy reference.
safety_data_sheet File Object Safety data sheet details. This file is also contained in the 'downloads' section. It is split out here as well for easy reference.
manufacturer_categories List of Category Objects Categorizations as outlined and provided by the manufacturer
facets List of Facet Objects A normalized subset of the specifications object where the specification names and values have been normalized across manufacturers
features List of Attribute Objects Marketing Information/Features in an attribute group. The attributes will not have a name
specifications List of Attribute Objects Product specifications in attribute groups. The attributes will have a name
downloads List of File Objects Downloads in file groups
videos List of File Objects Videos in file groups
etim ETIM Object International classification standard for technical products
certifications List of Certification Objects Certifications as provided by supplier
manufacturer_categories List of MFR Category Objects Categories as outlined by the manufacturer (where available)
images_360 List of 360 Image Objects 360 degree image delivered in an iframe url

Images and Sizes

Images and Sizes

{
        "name": "Scotch-Brite_Light_Duty_Cleansing_Pad_98.png",
        "display_name": "primary_image",
        "mime_type": "image/png",
        "weight": 10,
        "uri":"https://media.distributordatasolutions.com/xlsx_3M_synd/2021q1/images/large/8ee6ad83816f3f3f79d30b109bf570283b4a4953-large.png",
      "sizes":{
         "thumb":{
            "length":"4983",
            "uri":"https://media.distributordatasolutions.com/xlsx_3M_synd/2021q1/images/thumbnails/8ee6ad83816f3f3f79d30b109bf570283b4a4953-thumb.png"
         },
         "small":{
            "length":"31752",
            "uri":"https://media.distributordatasolutions.com/xlsx_3M_synd/2021q1/images/small/8ee6ad83816f3f3f79d30b109bf570283b4a4953-small.png"
         },
         "medium":{
            "length":"128403",
            "uri":"https://media.distributordatasolutions.com/xlsx_3M_synd/2021q1/images/medium/8ee6ad83816f3f3f79d30b109bf570283b4a4953-medium.png"
         },
         "large":{
            "length":"545958",
            "uri":"https://media.distributordatasolutions.com/xlsx_3M_synd/2021q1/images/large/8ee6ad83816f3f3f79d30b109bf570283b4a4953-large.png"
         },
         "native":{
            "length":"3367671",
            "uri":"https://media.distributordatasolutions.com/xlsx_3M_synd/2021q1/images/native/8ee6ad83816f3f3f79d30b109bf570283b4a4953-native.png"
         }
        }
    }

We supply multiple sizes of the same image. This allows you to choose the size appropriate for your needs. All of our images are hosted on our Content Delivery Network(CDN) powered by Amazon CloudFront. There is no need to download and host the files yourself. Every file will be served from and secure HTTPS domain with a valid certificate.

Image Object

Field Name Data Type Description
name String Often used for the filename attribute in the Content Disposition header
display_name String Usually shown as the text in the download link
mime_type String See Mozilla's documentation on Mime types here
weight Integer Used for sorting
uri Sting URI of the image on our CDN (https://media.distributordatasolutions.com/...)
sizes Sizes Object Object containing the parameters thumb, small, medium, large, and native

Sizes Object

Field Name Data Type Description
thumb Size Object Thumb Size Object. 64px x 62px Cropped*. Best for displaying in search results.
small Size Object Small Size Object. 256px x 256px Max*. Also good for displaying in search results or as the main image in your Product Details page.
medium Size Object Medium Size Object. 512px x 512px Max*. Good as the main Image in your Product Details Page.
large Size Object Large Size Object. 1024px x 1024px Max*. Good for a zoomed in version of the main image on the your Product Details page.
native Size Object Native Size Object. Original from manufacturer - Size varies. Good for a zoomed in version of the main image on your Product Details page.

Size Object

Field Name Data Type Description
uri String Fully qualified url of the image on our CDN.
size Number Size of the file in bytes. Not always present. Used to populate Content-length.

Spec Sheet and SDS (Simple File Object)

Spec Sheet and Safety Data Sheet (SDS)

{
    "name": "SB_Scouring Pads_HACCP INTL_Rev B.pdf",
    "display_name": "Spec Sheet",
    "mime_type": "application/pdf",
    "uri": "https://media.distributordatasolutions.com/xlsx_3M_synd/2021q1/documents/608f424ece035b3af473d03030b0412d7185c9fb.pdf",
}

Both the Spec Sheet and Safety data Sheet(SDS) have the same format.

Field Name Data Type Description
name String Name of the file
display_name String Spec Sheet or Safety Data Sheet
mime_type String typically "application/pdf". See Mime Types
uri String URL of the file on our CDN

360 Images

360 Images

"images_360": [
    {
        "cols":"24",
         "initial_image":"https://media.distributordatasolutions.com/xlsx_3M_synd/2021q1/360_images/medium/483ef5ff38ca15b34cd7debe629412e4583b5860-r01-c01-medium.png",
         "rows":"1",
         "filename":"483ef5ff38ca15b34cd7debe629412e4583b5860-r{row}-c{col}-medium.png",
         "initial_thumb":"https://media.distributordatasolutions.com/xlsx_3M_synd/2021q1/360_images/thumbnails/483ef5ff38ca15b34cd7debe629412e4583b5860-r01-c01-thumb.png",
         "filename_large":"483ef5ff38ca15b34cd7debe629412e4583b5860-r{row}-c{col}-native.png",
         "format":"row-column",
         "iframe_url":"https://media.distributordatasolutions.com/assets/magic360/viewer.html?initial=/xlsx_3M_synd/2021q1/360_images/medium/483ef5ff38ca15b34cd7debe629412e4583b5860-r01-c01-medium.png&filename=483ef5ff38ca15b34cd7debe629412e4583b5860-r{row}-c{col}-medium.png&rows=1&cols=24",
         "display_name":"5b953d11faff491882675e9914aea6bf 360 Image"
    }
],

Example iframe usage

<iframe src="https://media.distributordatasolutions.com/assets/magic360/viewer.html?initial=/xlsx_3M_synd/2021q1/360_images/medium/483ef5ff38ca15b34cd7debe629412e4583b5860-r01-c01-medium.png&filename=483ef5ff38ca15b34cd7debe629412e4583b5860-r{row}-c{col}-medium.png&rows=1&cols=24"></iframe>

A product may have 360 degree images available. If so, they will be present as an array in the images_360 key. DDS has provided a simple integration where you can embed a 360 viewer in an iframe. You only need to set the iframe_url value as the src for the iframe.

Packages

Packages

# NOTICE. Many of the packaging fields are null and therfore excluded
"packages": [
    {
        "code": "14a2edeb9f734eb395d7d0ddc87c491d",
        "gtin": "50042269002420",
        "qty": 25,
        "qty_uom": "CASE",
        "gross_weight": 10.5,
        "gross_weight_uom": "L",
        "pkg_length": 10,
        "pkg_length_uom": "IN",
        "pkg_height": 6.3,
        "pkg_height_uom": "IN",
        "pkg_width": 6.7,
        "pkg_width_uom": "IN",
        "description": "Case",
        "returnable": "Y"
    }
]

Package Object

Field Name Data Type Description
code String Unique DDS hash for the package
gtin String Usually GTIN-14, however could be any GTIN. see www.gtin.info.
sub_gtin String If the package contains smaller packaging. This is the GTIN of those packages.
sub_qty String Number of "sub" packages
qty String Quantity
qty_uom String Quantity Unit of Measure
gross_weight Number Weight
gross_weight_uom String Weight Unit of Measure
pkg_length Number Length
pkg_length_uom String Length Unit of Measure
pkg_height Number Height
pkg_height_uom String Height Unit of Measure
pkg_width Number Width
pkg_width_uom String Width Unit of Measure
description String An explanation of the packaging
returnable String Indicates if the product is returnable or not

Manufacturer

Manufacturer

"manufacturer": {
    "parent_id":32,
    "parent_name":"Legrand",
    "name":"Pass & Seymour",
    "id":33,
    "image": {
        "name":"primary_image",
        "mime_type":"image/png",
        "weight":30,
        "uri":"https://media.distributordatasolutions.com/ManufacturerLogos/Pass+%26+Seymour/_sized/primary_logo-large.png",
        "sizes": {
            "thumb": {
                "uri":"https://media.distributordatasolutions.com/ManufacturerLogos/Pass+%26+Seymour/_sized/primary_logo-thumb.png"
            },
            "small": {
                "uri":"https://media.distributordatasolutions.com/ManufacturerLogos/Pass+%26+Seymour/_sized/primary_logo-small.png"
            },
            "medium": {
                "uri":"https://media.distributordatasolutions.com/ManufacturerLogos/Pass+%26+Seymour/_sized/primary_logo-medium.png"
            },
            "large": {
                "uri":"https://media.distributordatasolutions.com/ManufacturerLogos/Pass+%26+Seymour/_sized/primary_logo-large.png"
            }
        }
    }
}

Object containing information about the manufacturer and its parent where applicable. (JSON only)

Manufacturer/Distributor Categories

Manufacturer/Distributor Categories

    "manufacturer_categories": [
        {
            "name": "ENERGY MANAGEMENT",
            "code": "49ae78b359f47eec973f84da57f48490"
        },
        {
            "name": "C I OCCUPANCY SENSORS",
            "parent_code": "49ae78b359f47eec973f84da57f48490",
            "code": "5dd16e922ba02ed5a7f5f72bd253ecd6"
        }
    ]

"distributor_categories":[
   {
      "category_id":690156,
      "code":"690156",
      "name":"Tools & Hardware"
   },
   {
      "category_id":690237,
      "code":"690237",
      "name":"Power Tools & Accessories",
      "parent_id":690156
   },
   {
      "category_id":690278,
      "code":"690278",
      "name":"Power Saws & Accessories",
      "parent_id":690237
   }
]

Manufacturer Categories provided directly from the manufacturer, or distributor specific categories and taxonomy.

Category Object

Field Name Data Type Description
category_id Integer Unique ID for each category
parent_id Integer References the parent category_id
code String UUID that uniquely identifies each category
parent_code String UUID that references back to the parent category
name String Category name

Facets

Facets

"facets": [
    {
        "data_key": "overall_length",
        "name": "Overall Length",
        "values": [
            {
                "value": "25.4",
                "value_with_uom": "25.4 millimeters",
                "uom_unit": "millimeter",
                "uom_unit_plural": "millimeters",
                "uom_abbreviation": "mm",
                "uom_abbreviation_plural": "mm"
            }
        ]
    },
    {
        "data_key": "material",
        "name": "Material",
        "values": [
            {
                "value": "ABS",
                "value_with_uom": "ABS"
            },
            {
                "value": "Plastic",
                "value_with_uom": "Plastic"
            }
        ]
    }
],

Facets are normalized and filterable attributes processed by our data team. They are extracted from product details and the unit of measure is separated, if applicable.

Facet Object

Field Name Data Type Description
data_key String Uniquely identifies the facet
name String Display name
values List of Facet value Objects List of facet values

Facet Value Object

Field Name Data Type Description
value String value without the unit of measure
value_with_uom String Value with the unit of measure added, considers pluralization
uom_unit String Singular text of the unit of measure
uom_unit_plural Plural version of the unit of measure
uom_abbreviation Singular abbreviation of the unit of measure
uom_abbreviation_plural Plural version of abbreviation of the unit of measure

Features and Specifications

Features and Specifications

"specifications": [
    {
        "group_name": "Busbar Cover Data",
        "group_items": [
            {
                "name": "Busbar Cover and Shroud",
                "value": "Individual Busbar Covers (for 10 mm Busbar)"
            }
        ]
    }
],
"features": [
   {
      "group_items":[
         {
            "value":"Internal flanges provide solid, twist-resistant shaft anchor",
            "weight":50
         },
         {
            "value":"Cushion-Grip handle allows for greater torque and comfort",
            "weight":30
         },
         {
            "value":"Hollow shank facilitates work on bolt applications",
            "weight":20
         },
         {
            "value":"Exclusive hollow shaft design with Rare Earth magnetic tip features unobstructed pass-through, even on long bolts",
            "weight":10
         },
         {
            "value":"Handle end is color coded for easy identification",
            "weight":40
         }
      ]
   },
   {
      "group_name":"Warnings",
      "group_items":[
         {
            "value":"NOT insulated. Will NOT protect against electrical shock.",
            "weight":20
         },
         {
            "value":"Always wear approved eye protection.",
            "weight":10
         }
      ]
   }
]

Features and Specifications are delivered in grouped attributes. It is typical for manufactures to group their data in sub sections to add another level of context. Each group has a name and a list of attributes.

Features

Feature are typically displayed on manufactures site's as a bulleted list

Specifications

Specifications are typically displayed on a manufacture site in name value pairs, with the name bold and followed by a colon. Another method is to put the name value pairs in a table but is less common.

Group Object (Attributes)

Field Name Data Type Description
group_name String Display name of the group
group_items List of Attribute Objects List of Attribute Objects that have name value pair

Attribute Object

Field Name Data Type Description
name String Display name for the attributes
value String Value

Downloads and Videos

Downloads and Videos

"downloads": [
    {
        "group_name": "Manuals",
        "group_items": [
            {
                "name": "22d-qs001_-en-p.pdf",
                "display_name": "Quick Start Manual",
                "mime_type": "application/pdf",
                "uri": "https://media.distributordatasolutions.com/AB-Symmetrix/2018q2/495d211239c5cc2cad89c4b2a4a1562ee0de50b4.pdf",
                "ext_hosted": 0,
                "weight": 10,
                "description": "(videos only)",
                "duration": "(videos only)",
                "embed_html": "(videos only)"
            },
        ]
    },

Downloads and Videos are delivered in grouped files. It is typical for manufactures to group their data in sub sections to add another level of context. Each group has a name and a list of files.

Group Object (Files)

Field Name Data Type Description
group_name String Display name of the group
group_items List of File Objects List of File Objects

File Object

Field Name Data Type Description
name String The name of the file
display_name String The display name for the file. Typically it is more human readable than the name.
mime_type String MimeType of the File
uri String Uri of the file or video. If ext_hosted is not 1, it will be hosted on our CDN.
ext_hosted String (Videos Only) 1 or null. If 1 use the "embedded_html" to display the video.
weight Int Used for sorting
description String a long description
duration String (Videos only) How long a Video is
embed_html String (Videos only) required when a video is hosted by an external provider (YouTube, Vimeo, etc...).

Multi CSV Implementation guide

Introduction

Welcome to the Multi CSV Implementation Guide. Below you will find general guidelines for default CSV format DDS provides out of the box. If your company has chosen a custom format, this guide may still be of use in understanding the underlying data.

Multi CSV

Multiple CSVs

The Default Multi CSV format will provide each of the following files:

Multiple files are necessary to more easily deliver the data that has multiple values for a single data type. For example, many products will have multiple downloadable files. These are contained in the downloads.csv.

All files contain a product_id column. In the items.csv file there is only one row per product_id. In all the other files there is the possibility of multiple rows per product_id. This allows for a one to many relationship. For instance, each product (one) has multiple downloads (many).

Separating the data into multiple files eliminates the need for numbered columns like document1,document2... and allows us to avoid a maximum number of items restriction and a large number of empty columns when a product does not have the maximum number. We can also include more relevant data for each item. For example, we provide a mime type, display name and a possible description for downloads.

CSV Standards

Our csv documents follow the RFC 4180 standard. A brief explanation is also available on the CSV wikipedia page (Scroll down to the RFC 4180 standard section).

Depending on the technology you use for you implementation you should set your csv settings to the following:

Configuration

Key Value Description
Header true All our CSVs have headers
Delimiter , Comma
Text Qualifier " Double quote. Columns are only wrapped with double quotes when the column text would break the parsing. This usually means the text contains a comma, double quote or a new line character.
Escape Character " Double Quote. Any double quote found in the text of a column will be preceded by another double quote. If the text has a double quote as the first character you will see 3 double quotes in a row. One for the start of the text, one as the escape character and the 3rd as the actually double character.

Item Details

Item Details

# items.csv

product_id,manufacturer_catalog_number,name,upc,manufacturer_name,product_title,long_description,short_description,invoice_description,rohs_indicator,family_code,preferred_product,length,length_uom,width,width_uom,height,height_uom,weight,weight_uom,sub_brand,custom_keywords,prop_65_message,ean,upc_11,retail_flag,country_of_origin,abc_classification,hazardous_material,manufacturer_product_group,region_id,list_price,units_qty,units_uom,price_country_of_origin,order_min,order_min_uom,order_increment,price_effective_date,price_expiration_date,currency,tariff_code,stocked,discount_code,price_group_code,sub_discount_code,standard_lead_time,export_commerce_control_number,business_group,product_life_cycle_status,language_code,tech_segment,next_effective_date,next_list_price,trade_price,user_price,dist_price,primary_thumb_uri,primary_image_name,primary_image_display_name,primary_image_mime_type,primary_image_thumb_uri,primary_image_small_uri,primary_image_medium_uri,primary_image_large_uri,primary_image_native_uri,primary_spec_sheet_uri,primary_spec_sheet_name,primary_spec_sheet_display_name,primary_spec_sheet_mime_type,safety_data_sheet_uri,safety_data_sheet_name,safety_data_sheet_display_name,safety_data_sheet_mime_type
Field Name Data Type Description
product_id String Unique Identifier
name String Product name
upc String UPC (technically refers to UPC-A) consists of 12 numeric digits, that are uniquely assigned to each product. Can have leading Zeros
manufacturer_name String Manufacturer of the product
product_title Sting Title of product if outlined by Manufacturer
short_description Sting Brief description of the product (will typically match the product name)
long_description String Longer description of the product
invoice_description String Description outlined by Manufacturer for invoicing
rohs_indicator String Restriction of Hazardous Substances Compliance
family_code String Identifies a product Group or Family. Defined by each individual manufacturer
preferred_product String Manufacturer will identify a list products which are "preferred". An "X" signifies a preferred product
length Double Length of the product
length_uom String Abbreviation of the unit of measure for the length (standard or imperial based on the region id)
width Double Width of the product
width_uom String Abbreviation of the unit of measure for the length (standard or imperial based on the region id)
height Double Height of the product
height_uom String Abbreviation of the unit of measure for the height (standard or imperial based on the region id)
weight Double Weight of the product
weight_uom String Abbreviation of the unit of measure for the height (standard or imperial based on the region id)
sub_brand String Sub Brand of Manufacturer
custom_keywords String Keywords typically used for SEO where outlined by Manufacturer
prop_65_message String Warning given for products sold in California
ean String European Article Number
upc_11 String 11 Digit UPC
retail_flag String
country_of_origin String Country where the product was manufactured
abc_classification String
hazardous_material String Flag where product is distinguished as a hazardous material
manufacturer_product_group String
region_id String Identifies which region the list price is associate with
list_price Decimal List price of the product for the specified region and currency
units_qty String
units_uom String
price_country_of_origin Decimal
order_min Integer Size of the minimum order as defined by the manufacturer
order_min_uom String
order_increment String
price_effective_date String Data when a list price starts for a product
price_expiration_date String Data when a list price ends for a product
currency String Currency of the list price
tariff_code String Tariff code
stocked String Stock status
discount_code String Manufacturer's discount code
price_group_code String
sub_discount_code String
standard_lead_time String
export_commerce_control_number String
business_group String
product_life_cycle_status String
language_code String
tech_segment String
next_effective_date String
next_list_price Decimal
trade_price Decimal
user_price Decimal
dist_price Decimal
primary_thumb_uri String
primary_image_name String Image file name
primary_image_display_name String Image display name
primary_image_mime_type String See Mozilla's documentation on Mime types here
primary_image_thumb_uri String Thumbnail sized image
primary_image_small_uri String Small sized image
primary_image_medium_uri String Medium sized image
primary_image_large_uri String Large sized image
primary_image_native_uri String Native sized image
primary_spec_sheet_uri String Primary spec sheet URI. This file is also contained in the 'downloads' section. It is split out here as well for easy reference.
primary_spec_sheet_name String Primary spec sheet file name
primary_spec_sheet_display_name String Display Name
primary_spec_sheet_mime_type String See Mozilla's documentation on Mime types here
safety_data_sheet_uri String
safety_data_sheet_name String
safety_data_sheet_display_name String
safety_data_sheet_mime_type String See Mozilla's documentation on Mime types here

Images and Sizes

Images and Sizes

# alternate-images.csv

 product_id, name, display_name, uri, mime_type, small_uri, medium_uri, large_uri, native_uri,

We supply multiple sizes of the same image. This allows you to choose the size appropriate for your needs. All of our images are hosted on our Content Delivery Network(CDN) powered by Amazon CloudFront. There is no need to download and host the files yourself. Every file will be served from and secure HTTPS domain with a valid certificate.

Image Object

Field Name Data Type Description
product_id String Unique Identifier
name String Often used for the filename attribute in the Content Disposition header
display_name String Usually shown as the text in the download link
mime_type String See Mozilla's documentation on Mime types here
small/medium/large/native uri String URI of the image on our CDN (https://media.distributordatasolutions.com/...)

Image Sizes

Field Name Description
thumb Thumb Size Object. 64px x 62px Cropped*. Best for displaying in search results.
small Small Size Object. 256px x 256px Max*. Also good for displaying in search results or as the main image in your Product Details page.
medium Medium Size Object. 512px x 512px Max*. Good as the main Image in your Product Details Page.
large Large Size Object. 1024px x 1024px Max*. Good for a zoomed in version of the main image on the your Product Details page.
native Native Size Object. Original from manufacturer - Size varies. Good for a zoomed in version of the main image on your Product Details page.

360 Images

# image360.csv

product_id,cols,rows,initial_image,filename,initial_thumb,filename_large,format,iframe_url,display_name
22017267,24,1,https://media.distributordatasolutions.com/xlsx_rubix_cube/2021q4/360_images/medium/ad88b0727c35474db7fd46e5d397d169ece27645-r01-c01-medium.png,ad88b0727c35474db7fd46e5d397d169ece27645-r{row}-c{col}-medium.png,https://media.distributordatasolutions.com/xlsx_rubix_cube/2021q4/360_images/thumbnails/ad88b0727c35474db7fd46e5d397d169ece27645-r01-c01-thumb.png,ad88b0727c35474db7fd46e5d397d169ece27645-r{row}-c{col}-native.png,row-column,https://media.distributordatasolutions.com/assets/magic360/viewer.html?initial=/xlsx_rubix_cube/2021q4/360_images/medium/ad88b0727c35474db7fd46e5d397d169ece27645-r01-c01-medium.png&filename=ad88b0727c35474db7fd46e5d397d169ece27645-r{row}-c{col}-medium.png&rows=1&cols=24,b14a9b7fb6df40c9bc0758ad00cee754 360 Image

# Example `iframe` usage

html
<iframe src="https://media.distributordatasolutions.com/assets/magic360/viewer.html?initial=/xlsx_3M_synd/2021q1/360_images/medium/483ef5ff38ca15b34cd7debe629412e4583b5860-r01-c01-medium.png&filename=483ef5ff38ca15b34cd7debe629412e4583b5860-r{row}-c{col}-medium.png&rows=1&cols=24"></iframe>

A product may have 360 degree images available. If so, they will be present in the image_360.csv file. DDS has provided a simple integration where you can embed a 360 viewer in an iframe. You only need to set the iframe_url value as the src for the iframe.

Manufacturer Categories

Categories

# manufacturer-categories.csv

product_id,category_id,parent_id,code,name
22017267,1293942,1293941,049e3087778fb9a172b31b19dd442a0e,Cubes
22017267,1293941,"",75a590f43c0627b38b8c3e6f7c557313,Objects
22017267,1293943,1293942,d0e32a31200e8055acf38eacf420a022,Rubix Cubes

Manufacturer categories (also known as taxonomy) is a 3 level deep classification where available from the manufacturer.

Category Object

Field Name Data Type Description
category_id Integer Unique ID for each category
parent_id Integer References the parent category_id
code String UUID that uniquely identifies each category
name String Category name

Facets

Facets

#facets.csv

product_id,data_key,name,value,value_with_uom,uom_unit,uom_unit_plural,uom_abbreviation,uom_abbreviation_plural
99999,overall_length,Overall Length,25.4,25.4 millimeters,millimeter,millimeters,mm,mm
88888,material,Material,ABS,ABS,,,,,
88888,material,Material,Plastic,Plastic,,,,,
#facet-keys.csv

data_key,name
overal_length,Overall Length
material,Material

Facets are normalized and filterable attributes processed by our data team. They are extracted from product details and the unit of measure is separated, if applicable.

Multi-CSV

Facets in the Multi-CSV delivery are de-normalized. We provide two files: facets.csv and facet-keys.csv. A facet can have multiple values. For example, a product can have more than one color. Consider a black and yellow DEWALT drill. facets.csv has a row for every facet value and therefore can have multiple per product id and facet key.

facet-keys.csv is list of distinct facet_keys and names. Some client like to pre-process the facet keys to identify internal ids and then process the facet values.

Facet Object

Field Name Data Type Description
data_key String Uniquely identifies the facet
name String Display name
values List of Facet value Objects List of facet values

Facet Value Object

Field Name Data Type Description
value String value without the unit of measure
value_with_uom String Value with the unit of measure added, considers pluralization
uom_unit String Singular text of the unit of measure
uom_unit_plural Plural version of the unit of measure
uom_abbreviation Singular abbreviation of the unit of measure
uom_abbreviation_plural Plural version of abbreviation of the unit of measure

Features and Specifications

Features and Specifications

# features.csv/specifications.csv

product_id,group_name,name,value,weight
22017267,Applications,"",Universal applications,0
22017267,"","",Endless entertainment,10
22017267,"","",Multi-colored,0
22017267,"","",A 10 cent piece of plastic,20
22017267,Includes,"",Nothing else,10
22017267,Includes,"",A single cube,0

Features and Specifications are delivered in grouped attributes. It is typical for manufactures to group their data in sub sections to add another level of context. Each group has a name and a list of attributes.

Features

Features are typically displayed on manufacturer's sites as a bulleted list

Specifications

Specifications are typically displayed on a manufacturer site in name value pairs, with the name bold and followed by a colon. Another method is to put the name value pairs in a table but is less common.

Group Object (Attributes)

Field Name Data Type Description
group_name String Display name of the group
group_items List of Attribute Objects List of Attribute Objects that have name value pair

Attribute Object

Field Name Data Type Description
name String Display name for the attributes
value String Value

Downloads and Videos

Downloads and Videos

# downloads.csv/videos.csv

product_id,group_name,name,display_name,mime_type,uri,ext_hosted,weight,description,duration,embed_html
22017267,Solution,Rubix_cube_solution.pdf,Solution Manual,application/pdf,https://media.distributordatasolutions.com/xlsx_rubix_cube/2021q4/documents/c339bd52ca5daa5162b8cecc897056520acf0539.pdf,0,0,"","",""
22017267,"",RBL_solve_guide_CUBE_US_5.375x8.375in_AW_27Feb2020_VISUAL.pdf,Catalog,application/pdf,https://media.distributordatasolutions.com/xlsx_rubix_cube/2021q4/documents/6e33c73e2588c97dfacc466ce20ab101eac2a190.pdf,0,30,"","",""

Downloads and Videos are delivered in grouped files. It is typical for manufactures to group their data in sub sections to add another level of context. Each group has a name and a list of files.

Group Object (Files)

Field Name Data Type Description
group_name String Display name of the group
group_items List of File Objects List of File Objects

File Object

Field Name Data Type Description
name String The name of the file
display_name String The display name for the file. Typically it is more human readable than the name.
mime_type String MimeType of the File
uri String Uri of the file or video. If ext_hosted is not 1, it will be hosted on our CDN.
ext_hosted String (Videos Only) 1 or null. If 1 use the "embedded_html" to display the video.
weight Int Used for sorting
description String a long description
duration String (Videos only) How long a Video is
embed_html String (Videos only) required when a video is hosted by an external provider (YouTube, Vimeo, etc...).

XML Implementation guide

Introduction

Welcome to the XML Implementation Guide. Below you will find general guidelines for default XML format DDS provides out of the box. If your company has chosen a custom format, this guide may still be of use in understanding the underlying data.

Multi Part files

Our default XML data is in multiple part files. There will be many files in the delivered directory. Filenames will follow the format part-{UUID with dashes}.xml. The files only contain root level tag () with nested () tags/objects. By default no header object is included. All file data is UTF8 encoded.

XML NULL values

Null values are excluded in our XML files fields. Any code you use to parse the XML will need to handle the absence of a field you expect to be present. For example, not all manufacturers supply packaging dimensions. Rather than providing an empty packaging tag, the tag is omitted.

# Example of one XML root and row objects per part file
<products>
  <product>.....</product>
  <product>.....</product>
  <product>.....</product>
</products>

Product

Product

<product>
  <manufacturer_name>Generic Manufacturer</manufacturer_name>
  <code>a413f8e07a249a7be2cbefe510996fd3</code>
  <manufacturer_catalog_number>NSYCVF85M230PF</manufacturer_catalog_number>
  <name>Generic Product Name</name>
  <upc>78590169865</upc>
  <price>
    <region_id>USA</region_id>
    <list_price>999.99</list_price>
    <country_of_origin>FR</country_of_origin>
    <price_effective_date>2019-10-01</price_effective_date>
    <stocked>Non-S</stocked>
    <standard_lead_time>15</standard_lead_time>
  </price>
  <primary_image>
    <name>DB300479_4000x4000.png</name>
    <display_name>IMAGE</display_name>
    <mime_type>image/png</mime_type>
    <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/8f0721ce74a631bd2533af863d407dcd2e3de6d0-large.png</uri>
    <sizes>
      <thumb>
        <length>3447</length>
        <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/8f0721ce74a631bd2533af863d407dcd2e3de6d0-thumb.png</uri>
      </thumb>
      <small>
        <length>6903</length>
        <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/8f0721ce74a631bd2533af863d407dcd2e3de6d0-small.png</uri>
      </small>
      <medium>
        <length>6903</length>
        <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/8f0721ce74a631bd2533af863d407dcd2e3de6d0-medium.png</uri>
      </medium>
      <large>
        <length>6903</length>
        <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/8f0721ce74a631bd2533af863d407dcd2e3de6d0-large.png</uri>
      </large>
      <native>
        <length>6903</length>
        <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/8f0721ce74a631bd2533af863d407dcd2e3de6d0-native.png</uri>
      </native>
    </sizes>
  </primary_image>
  <alternate_images>
    <alternate_image>
      <name>DB300387_4000x4000.png</name>
      <display_name>High Res PNG</display_name>
      <mime_type>image/png</mime_type>
      <weight>10</weight>
      <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/e6f8051c914ae9c2ce0c9b4b22ef442500276aa0-large.png</uri>
      <sizes>
        <thumb>
          <length>3626</length>
          <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/e6f8051c914ae9c2ce0c9b4b22ef442500276aa0-thumb.png</uri>
        </thumb>
        <small>
          <length>10627</length>
          <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/e6f8051c914ae9c2ce0c9b4b22ef442500276aa0-small.png</uri>
        </small>
        <medium>
          <length>10627</length>
          <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/e6f8051c914ae9c2ce0c9b4b22ef442500276aa0-medium.png</uri>
        </medium>
        <large>
          <length>10627</length>
          <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/e6f8051c914ae9c2ce0c9b4b22ef442500276aa0-large.png</uri>
        </large>
        <native>
          <length>10627</length>
          <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/e6f8051c914ae9c2ce0c9b4b22ef442500276aa0-native.png</uri>
        </native>
      </sizes>
    </alternate_image>
  </alternate_images>
  <primary_spec_sheet>
    <name>ClimaSys_NSYCVF85M230PF.pdf</name>
    <display_name>Product Datasheet (pdf)</display_name>
    <mime_type>application/pdf</mime_type>
    <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/722f89fc2e124968b7ebb3734d089b4f595ea7f7.pdf</uri>
    <weight>10</weight>
  </primary_spec_sheet>
  <safety_data_sheet>
    <name>msds.pdf</name>
    <display_name>Manufacturer Safety Datasheet (pdf)</display_name>
    <mime_type>application/pdf</mime_type>
    <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/722f89fc2e124968b7ebb3734d089b4f595ea7f7.pdf</uri>
    <weight>10</weight>
  </safety_data_sheet>
  <packages>
    <package>
      <gtin>00785901698654</gtin>
      <gross_weight>0.84</gross_weight>
      <gross_weight_uom>Lbs</gross_weight_uom>
    </package>
  </packages>
  <facets>
    <facet>
      <data_key>color</data_key>
      <name>Color</name>
      <values>
        <value>
          <facet_value>Outlet Grille Grey RAL 7035)</facet_value>
          <value_with_uom>Outlet Grille Grey RAL 7035)</value_with_uom>
        </value>
      </values>
    </facet>
    <facet>
      <data_key>country_of_origin</data_key>
      <name>Country of Origin</name>
      <values>
        <value>
          <facet_value>France</facet_value>
          <value_with_uom>France</value_with_uom>
        </value>
      </values>
    </facet>
  </facets>
  <categories>
    <category>
      <category_id>445162</category_id>
      <code>193c73ee12e172017850cbcb9025344e</code>
      <name>Thermal Management</name>
      <parent_id>443023</parent_id>
    </category>
    <category>
      <category_id>443022</category_id>
      <code>6289ca5fa1962a331a79fb511330eef0</code>
      <name>Electrical Enclosures &amp; Boxes</name>
    </category>
    <category>
      <category_id>443023</category_id>
      <code>b580b3d6dae788677ecddba162e2153c</code>
      <name>Enclosure Accessories</name>
      <parent_id>443022</parent_id>
    </category>
  </categories>
  <image_360>
    <cols>24</cols>
    <rows>1</rows>
    <initial_image>https://media.distributordatasolutions.com/XXXXXXX/2021q2/360_images/medium/000014d91bcfa43ad4eacb2c6a2b670c9ce836ec-r01-c01-medium.png</initial_image>
    <filename>000014d91bcfa43ad4eacb2c6a2b670c9ce836ec-r01-c01-medium.png</filename>
    <initial_thumb>https://media.distributordatasolutions.com/XXXXXXX/2021q2/360_images/thumb/000014d91bcfa43ad4eacb2c6a2b670c9ce836ec-r01-c01-thumb.png</initial_thumb>
    <filename_large>000014d91bcfa43ad4eacb2c6a2b670c9ce836ec-r01-c01-large.png</filename_large>
    <format>png</format>
    <iframe_url>
      <iframe src="https://media.distributordatasolutions.com/assets/magic360/viewer.html?initial=/xlsx_3M_synd/2021q1/360_images/medium/483ef5ff38ca15b34cd7debe629412e4583b5860-r01-c01-medium.png&filename=483ef5ff38ca15b34cd7debe629412e4583b5860-r{row}-c{col}-medium.png&rows=1&cols=24">
      </iframe>
    </iframe_url>
    <display_name>000014d91bcfa43ad4eacb2c6a2b670c9ce836ec 360 image</display_name>
  </image_360>
  <features>
    <group>
      <group_name>Warnings</group_name>
      <group_items>
        <item>
          <value>NOT insulated. Will NOT protect against electrical shock.</value>
          <weight>20</weight>
        </item>
        <item>
          <value>Always wear approved eye protection.</value>
          <weight>10</weight>
        </item>
      </group_items>
    </group>
  </features>
  <specifications>
    <group>
      <group_name>Complementary</group_name>
      <group_items>
        <item>
          <name>Absorbed Power</name>
          <value>15 W 60 Hz || 17 W 50 Hz</value>
          <weight>80</weight>
        </item>
      </group_items>
    </group>
    <group>
      <group_name>Contractual Warranty</group_name>
      <group_items>
        <item>
          <name>Warranty</name>
          <value>18 months</value>
          <weight>360</weight>
        </item>
      </group_items>
    </group>
    <group>
      <group_name>Main</group_name>
      <group_items>
        <item>
          <name>Flow Rate</name>
          <value>Free flow rate with standard filter 22455.03 Gal/hr(US) (85 m3/h) 50 Hz || Free flow rate with standard filter 25889.32 Gal/hr(US) (98 m3/h) 60 Hz</value>
          <weight>50</weight>
        </item>
      </group_items>
    </group>
    <group>
      <group_name>Offer Sustainability</group_name>
      <group_items>
        <item>
          <name>California Proposition 65</name>
          <value>WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov</value>
          <weight>320</weight>
        </item>
      </group_items>
    </group>
    <group>
      <group_name>Ordering And Shipping Details</group_name>
      <group_items>
        <item>
          <name>Category</name>
          <value>80036 - ENCLOSURE SYSTEMS ACCESSORIES</value>
          <weight>260</weight>
        </item>
      </group_items>
    </group>
  </specifications>
  <downloads>
    <group>
      <group_items>
        <item>
          <name>SB200482_3D-simplified</name>
          <display_name>Filterfan 85m3/h 230V IP54 (stp)</display_name>
          <mime_type>application/step</mime_type>
          <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/51a1970b8fda1ed93500ecac7fb7c578990de424</uri>
          <ext_hosted>0</ext_hosted>
          <weight>90</weight>
          <locale>en-US</locale>
          <manufacturer_file_id>SB200482_3D-simplified</manufacturer_file_id>
        </item>
      </group_items>
    </group>
  </downloads>
  <videos>
    <group>
      <group_items>
        <item>
          <name>Locating Coil Consumption Details on RXG Interface Relays</name>
          <mime_type>text/html</mime_type>
          <uri>https://www.youtube.com/embed/W6W-90ovcos</uri>
          <ext_hosted>1</ext_hosted>
          <weight>20</weight>
          <locale>en-US</locale>
          <description>Tutorial for locating the Coil Consumption Details                        </description>
        </item>
      </group_items>
    </group>
  </videos>
  <etim>
    <group_code>EG00001</group_code>
    <group_description>generic group</group_description>
    <class_code>EC00001</class_code>
    <class_description>generic class</class_description>
    <version>7</version>
    <features>
      <feature_code>EF00001</feature_code>
      <value_code>EV00001</value_code>
      <value_string>generic value</value_string>
      <feature_name>generic feature</feature_name>
    </features>
  </etim>
  <product_title>XB5 Head with Key, 22 mm, Plastic Bezel, 3-Pos., Stay-Put</product_title>
  <long_description>This head with key (key no.520E) provides a versatile interface for controlling your machines. It is easily installed and replaced on compatible complete key selector switch units. It provides a secure manner for authorized staff to switch between process or machine operating modes. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66. It makes it ideal for operation in harsh environments.</long_description>
  <short_description>ClimaSys forced vent. IP54, 85m3/h, 230V, with outlet grille and filter G2</short_description>
  <invoice_description>ClimaSys forced vent. IP54, 85m3/h, 230V, with outlet grille and filter G2</invoice_description>
  <rohs_indicator>X</rohs_indicator>
  <family_code>123ABC</family_code>
  <preferred_product>N</preferred_product>
  <length>1.0</>
  <length_uom>in</>
  <width>1.0</>
  <width_uom>in</>
  <height>1.0</>
  <height_uom>in</>
  <weight>1.0</>
  <weight_uom>in</>
  <sub_brand>Sub Brand</sub_brand>
  <custom_keywords>[Us] rated supply voltage:175...253 V|air flow:free flow rate with standard filter: 22455.03 Gal/hr(US) (85 m3/h) at 50 Hz,free flow rate with standard filter: 25889.32 Gal/hr(US) (98 m3/h) at 60 Hz|input voltage:230 V 50/60 Hz|product name:ClimaSys CV|product or component type:fan|range:ClimaSys|type of ventilation filter:standard</custom_keywords>
  <prop_65_message>This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov</prop_65_message>
  <ean>3606480151200</ean>
  <upc_11>78590169865</upc_11>
  <retail_flag>true</retail_flag>
  <country_of_origin>FR</country_of_origin>
  <abc_classification>500A</abc_classification>
  <hazardous_material>false</hazardous_material>
  <manufacturer_product_group>123ABC</manufacturer_product_group>
</product>
Field Name Data Type Description
manufacturer_name String name of product manufacturer
code String UUID assigned by DDS to each product
manufacturer_catalog_number String Uniquely Identifies the product within a manufacturer
name String Product name
price Price Object See Price
primary_image Image Object see Images and Sizes
alternate_images List of Image Objects see Images and Sizes
primary_spec_sheet File Object see Spec Sheet and SDS (Simple File Object)
safety_data_sheet File Object see Spec Sheet and SDS (Simple File Object)
packages List Package Objects see Packages
facets List of Facet Objects see Facets
categories List of Category Objects see Categories
image_360 Image 360 Object see 360 Images
features List of Attribute Objects Marketing Information/Features in an attribute group. The attributes will not have a name. See Features and Specifications
specifications List of Attribute Objects Product specifications in attribute groups. The attributes will have a name. See Features and Specifications
downloads List of File Object Downloads in file groups
videos List of File Objects Videos in file groups
etim ETIM Object International classification standard for technical products. See ETIM Object
product_title String Manufacturer metadata title for product
long_description String Manufacturer long description of product
short_description String Manufacturer short description of product
invoice_description String Manufacturer invoice/order sheet description of product
rohs_indicator String Flag to identify product as RoHS.
family_code String Identifies a product Group or Family. Defined by each individual manufacturer
preferred_product String Manufacturer will identify a list products which are "preferred". An "X" signifies a preferred product
length Double Length of the product
length_uom String Abbreviation of the unit of measure for the length (standard or imperial based on the region id)
width Double Width of the product
width_uom String Abbreviation of the unit of measure for the length (standard or imperial based on the region id)
height Double Height of the product
height_uom String Abbreviation of the unit of measure for the length (standard or imperial based on the region id)
weight Double Weight of the product
weight_uom String Abbreviation of the unit of measure for the length (standard or imperial based on the region id)
sub_brand String Additional branding of the product
custom_keywords String Pipe delimited manufacturer keywords
prop_65_message String Warning given for products sold in California
ean String European Article Number
upc_11 String 11 Digit UPC
retail_flag String
country_of_origin String Country where the product was manufactured
abc_classification String
hazardous_material String Flag where product is distinguished as a hazardous material
manufacturer_product_group String

Images and Sizes

Images and Sizes

<name>DB300479_4000x4000.png</name>
<display_name>IMAGE</display_name>
<mime_type>image/png</mime_type>
<uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/8f0721ce74a631bd2533af863d407dcd2e3de6d0-large.png</uri>
<sizes>
  <thumb>
    <length>3447</length>
    <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/8f0721ce74a631bd2533af863d407dcd2e3de6d0-thumb.png</uri>
  </thumb>
  <small>
    <length>6903</length>
    <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/8f0721ce74a631bd2533af863d407dcd2e3de6d0-small.png</uri>
  </small>
  <medium>
    <length>6903</length>
    <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/8f0721ce74a631bd2533af863d407dcd2e3de6d0-medium.png</uri>
  </medium>
  <large>
    <length>6903</length>
    <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/8f0721ce74a631bd2533af863d407dcd2e3de6d0-large.png</uri>
  </large>
  <native>
    <length>6903</length>
    <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/8f0721ce74a631bd2533af863d407dcd2e3de6d0-native.png</uri>
  </native>
</sizes>

We supply multiple sizes of the same image. This allows you to choose the size appropriate for your needs. All of our images are hosted on our Content Delivery Network(CDN) powered by Amazon CloudFront. There is no need to download and host the files yourself. Every file will be served from and secure HTTPS domain with a valid certificate.

Image Object

Field Name Data Type Description
name String Often used for the filename attribute in the Content Disposition header
display_name String Usually shown as the text in the download link
mime_type String See Mozilla's documentation on Mime types here
weight Integer Used for sorting
uri Sting URI of the image on our CDN (https://media.distributordatasolutions.com/...)
sizes Sizes Object Object containing the parameters thumb, small, medium, large, and native

Sizes Object

Field Name Data Type Description
thumb Size Object Thumb Size Object. 64px x 62px Cropped*. Best for displaying in search results.
small Size Object Small Size Object. 256px x 256px Max*. Also good for displaying in search results or as the main image in your Product Details page.
medium Size Object Medium Size Object. 512px x 512px Max*. Good as the main Image in your Product Details Page.
large Size Object Large Size Object. 1024px x 1024px Max*. Good for a zoomed in version of the main image on the your Product Details page.
native Size Object Native Size Object. Original from manufacturer - Size varies. Good for a zoomed in version of the main image on your Product Details page.

Size Object

Field Name Data Type Description
uri String Fully qualified url of the image on our CDN.
length Number Size of the file in bytes. Not always present. Used to populate Content-length.

Spec Sheet and SDS (Simple File Object)

Spec Sheet and Safety Data Sheet (SDS)

<name>ClimaSys_NSYCVF85M230PF.pdf</name>
<display_name>Product Datasheet (pdf)</display_name>
<mime_type>application/pdf</mime_type>
<uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/722f89fc2e124968b7ebb3734d089b4f595ea7f7.pdf</uri>
<weight>10</weight>

Both the Spec Sheet and Safety data Sheet(SDS) have the same format.

Field Name Data Type Description
name String Name of the file
display_name String Spec Sheet or Safety Data Sheet
mime_type String typically "application/pdf". See Mime Types
uri String URL of the file on our CDN
weight Integer value used for sorting

Packages

Packages

# NOTICE. Many of the packaging fields are null and therfore excluded
<packages>
  <package>
    <gtin>00785901698654</gtin>
    <gross_weight>0.84</gross_weight>
    <gross_weight_uom>Lbs</gross_weight_uom>
  </package>
</packages>

Package Object

Field Name Data Type Description
code String Unique DDS hash for the package
gtin String Usually GTIN-14, however could be any GTIN. see www.gtin.info.
sub_gtin String If the package contains smaller packaging. This is the GTIN of those packages.
sub_qty String Number of "sub" packages
qty String Quantity
qty_uom String Quantity Unit of Measure
gross_weight Number Weight
gross_weight_uom String Weight Unit of Measure
pkg_length Number Length
pkg_length_uom String Length Unit of Measure
pkg_height Number Height
pkg_height_uom String Height Unit of Measure
pkg_width Number Width
pkg_width_uom String Width Unit of Measure
description String An explanation of the packaging
returnable String Indicates if the product is returnable or not

Facets

Facets

# NOTICE. Some facets do not contain/require a uom and therefore omit the uom_unit_plural, uom_abbreviation, and uom_abbreviation_plural
<facets>
  <facet>
    <data_key>standard</data_key>
    <name>Standard</name>
    <values>
      <value>
        <facet_value>IEC 62208</facet_value>
        <value_with_uom>IEC 62208</value_with_uom>
      </value>
    </values>
  </facet>
  <facet>
    <data_key>weight</data_key>
    <name>Weight</name>
    <values>
      <value>
        <facet_value>38</facet_value>
        <value_with_uom>38 kilograms</value_with_uom>
        <uom_unit>kilogram</uom_unit>
        <uom_unit_plural>kilograms</uom_unit_plural>
        <uom_abbreviation>kg</uom_abbreviation>
        <uom_abbreviation_plural>kg</uom_abbreviation_plural>
      </value>
    </values>
    <values>
      <value>
        <facet_value>83.78</facet_value>
        <value_with_uom>83.78 pounds</value_with_uom>
        <uom_unit>pound</uom_unit>
        <uom_unit_plural>pounds</uom_unit_plural>
        <uom_abbreviation>lb</uom_abbreviation>
        <uom_abbreviation_plural>lbs</uom_abbreviation_plural>
      </value>
    </values>
  </facet>
</facets>

Facets are normalized and filterable attributes processed by our data team. They are extracted from product details and the unit of measure is separated, if applicable.

Facet Object

Field Name Data Type Description
data_key String Uniquely identifies the facet
name String Display name
values List of Facet value Objects List of facet values

Facet Value Object

Field Name Data Type Description
facet_value String value without the unit of measure
value_with_uom String Value with the unit of measure added, considers pluralization
uom_unit String Singular text of the unit of measure
uom_unit_plural Plural version of the unit of measure
uom_abbreviation Singular abbreviation of the unit of measure
uom_abbreviation_plural Plural version of abbreviation of the unit of measure

Manufacturer/Distributor Categories

Manufacturer/Distributor Categories

<manufacturer_categories>
  <category>
    <category_id>445162</category_id>
    <code>193c73ee12e172017850cbcb9025344e</code>
    <name>Thermal Management</name>
    <parent_id>443023</parent_id>
  </category>
  <category>
    <category_id>443022</category_id>
    <code>6289ca5fa1962a331a79fb511330eef0</code>
    <name>Electrical Enclosures &amp; Boxes</name>
  </category>
  <category>
    <category_id>443023</category_id>
    <code>b580b3d6dae788677ecddba162e2153c</code>
    <name>Enclosure Accessories</name>
    <parent_id>443022</parent_id>
  </category>
</manufacturer_categories>

Manufacturer Categories provided directly from the manufacturer, or distributor specific categories and taxonomy.

Category Object

Field Name Data Type Description
category_id Integer Unique ID for each category
code String UUID that uniquely identifies each category
name String Category name
parent_id Integer References the parent category_id

360 Images

360 Images

<image_360>
  <cols>24</cols>
  <rows>1</rows>
  <initial_image>https://media.distributordatasolutions.com/XXXXXXX/2021q2/360_images/medium/000014d91bcfa43ad4eacb2c6a2b670c9ce836ec-r01-c01-medium.png</initial_image>
  <filename>000014d91bcfa43ad4eacb2c6a2b670c9ce836ec-r01-c01-medium.png</filename>
  <initial_thumb>https://media.distributordatasolutions.com/XXXXXXX/2021q2/360_images/thumb/000014d91bcfa43ad4eacb2c6a2b670c9ce836ec-r01-c01-thumb.png</initial_thumb>
  <filename_large>000014d91bcfa43ad4eacb2c6a2b670c9ce836ec-r01-c01-large.png</filename_large>
  <format>ow-column</format>
  <iframe_url>
    <iframe src="https://media.distributordatasolutions.com/assets/magic360/viewer.html?initial=/xlsx_3M_synd/2021q1/360_images/medium/483ef5ff38ca15b34cd7debe629412e4583b5860-r01-c01-medium.png&filename=483ef5ff38ca15b34cd7debe629412e4583b5860-r{row}-c{col}-medium.png&rows=1&cols=24"></iframe>
  </iframe_url>
  <display_name>000014d91bcfa43ad4eacb2c6a2b670c9ce836ec 360 image</display_name>
</image_360>

Image 360 Object

Field Name Data Type Description
cols Integer
rows Integer
initial_image String Naming convention of medium 360 image
filename String Category name
initial_thumb String URI for first of thumb sized 360 images
filename_large String Naming convention of large 360 images
format String Format of 360 images
iframe_url String Preconfigured 360 image viewer hosted by DDS.
display_name String Display name of image

Example iframe_url usage

<iframe src="https://media.distributordatasolutions.com/assets/magic360/viewer.html?initial=/xlsx_3M_synd/2021q1/360_images/medium/483ef5ff38ca15b34cd7debe629412e4583b5860-r01-c01-medium.png&filename=483ef5ff38ca15b34cd7debe629412e4583b5860-r{row}-c{col}-medium.png&rows=1&cols=24"></iframe>

DDS has provided a simple integration where you can embed a 360 viewer in an iframe. You only need to set the iframe_url value as the src for the iframe.

Features and Specifications

Features and Specifications

<features>
  <group>
    <group_name>Warnings</group_name>
    <group_items>
      <item>
        <value>NOT insulated. Will NOT protect against electrical shock.</value>
        <weight>20</weight>
      </item>
      <item>
        <value>Always wear approved eye protection.</value>
        <weight>10</weight>
      </item>
    </group_items>
  </group>
</features>
<specifications>
  <group>
    <group_name>Complementary</group_name>
    <group_items>
      <item>
        <name>Absorbed Power</name>
        <value>15 W 60 Hz || 17 W 50 Hz</value>
        <weight>80</weight>
      </item>
    </group_items>
  </group>
  <group>
    <group_name>Contractual Warranty</group_name>
    <group_items>
      <item>
        <name>Warranty</name>
        <value>18 months</value>
        <weight>360</weight>
      </item>
    </group_items>
  </group>
  <group>
    <group_name>Main</group_name>
    <group_items>
      <item>
        <name>Flow Rate</name>
        <value>Free flow rate with standard filter 22455.03 Gal/hr(US) (85 m3/h) 50 Hz || Free flow rate with standard filter 25889.32 Gal/hr(US) (98 m3/h) 60 Hz</value>
        <weight>50</weight>
      </item>
    </group_items>
  </group>
  <group>
    <group_name>Offer Sustainability</group_name>
    <group_items>
      <item>
        <name>California Proposition 65</name>
        <value>WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov</value>
        <weight>320</weight>
      </item>
    </group_items>
  </group>
  <group>
    <group_name>Ordering And Shipping Details</group_name>
    <group_items>
      <item>
        <name>Category</name>
        <value>80036 - ENCLOSURE SYSTEMS ACCESSORIES</value>
        <weight>260</weight>
      </item>
    </group_items>
  </group>
</specifications>

Features and Specifications are delivered in grouped attributes. It is typical for manufactures to group their data in sub sections to add another level of context. Each group has a name and a list of attributes.

Features

Feature are typically displayed on manufactures sites as a bulleted list

Specifications

Specifications are typically displayed on a manufacture site in name value pairs, with the name bold and followed by a colon. Another method is to put the name value pairs in a table but is less common.

Group Object (Attributes)

Field Name Data Type Description
group_name String Display name of the group
group_items List of Attribute Objects List of Attribute Objects that have name value pair

Attribute Object

Field Name Data Type Description
name String Display name for the attributes
value String Value
weight Integer Numeric value used for sorting/display.

Downloads and Videos

Downloads and Videos

<downloads>
  <group>
    <group_items>
      <item>
        <name>SB200482_3D-simplified</name>
        <display_name>Filterfan 85m3/h 230V IP54 (stp)</display_name>
        <mime_type>application/step</mime_type>
        <uri>https://media.distributordatasolutions.com/XXXXXXX/2019q3/51a1970b8fda1ed93500ecac7fb7c578990de424</uri>
        <ext_hosted>0</ext_hosted>
        <weight>90</weight>
        <locale>en-US</locale>
        <manufacturer_file_id>SB200482_3D-simplified</manufacturer_file_id>
      </item>
    </group_items>
  </group>
</downloads>
<videos>
  <group>
    <group_items>
      <item>
        <name>Locating Coil Consumption Details on RXG Interface Relays</name>
        <mime_type>text/html</mime_type>
        <uri>https://www.youtube.com/embed/W6W-90ovcos</uri>
        <ext_hosted>1</ext_hosted>
        <weight>20</weight>
        <locale>en-US</locale>
        <description>Tutorial for locating the Coil Consumption Details</description>
      </item>
    </group_items>
  </group>
</videos>

Group Object (Files)

Field Name Data Type Description
group_items List of File Objects List of File Objects

File Object

Field Name Data Type Description
name String The name of the file
display_name String The display name for the file. Typically it is more human readable than the name.
mime_type String MimeType of the File
uri String Uri of the file or video. If ext_hosted is not 1, it will be hosted on our CDN.
ext_hosted String (Videos Only) 1 or null. If 1 use the "embedded_html" to display the video.
weight Int Used for sorting
description String a long description
duration String (Videos only) How long a Video is
embed_html String (Videos only) required when a video is hosted by an external provider (YouTube, Vimeo, etc...).

Etim

Etim

<etim>
  <group_code>EG00001</group_code>
  <group_description>generic group</group_description>
  <class_code>EC00001</class_code>
  <class_description>generic class</class_description>
  <version>7</version>
  <features>
    <feature>
      <feature_code>EF000073</feature_code>
      <value_code>EV009241</value_code>
      <feature_name>Suitable for</feature_name>
    </feature>
    <feature>
      <feature_code>EF007092</feature_code>
      <value_string>25</value_string>
      <unit_code>EU570448</unit_code>
      <feature_name>Width clamp</feature_name>
      <unit_name>Millimetre</unit_name>
    </feature>
  </features>
</etim>

ETIM Object

Field Name Data Type Description
group_code String ETIM code for the group to which the product belongs
group_description String Name of ETIM group to which the product belongs
class_code String ETIM code for the class within the group to which the product belongs
class_description String ETIM description for the class within the group to which the product belongs
version String ETIM verions
features List of Feature Object See Feature Object

Feature Object

Field Name Data Type Description
feature_code String ETIM feature code
value_string String Value for feature if not a code
unit_code String ETIM uom code
feature_name String Name of the feature
unit_name String Name of the unit of measure

File Delivery

Files will be delivered over SFTP. DDS will provide a username and password that will allow access to the host sftp.distds.com

A decent, free option is FileZilla.

After starting FileZilla, click the Site Manager button.

In the Site Manager, click the "New Site" button.

Immediately type in a name that will help you remember the site, like "DDS", then hit return. Click the protocol selection button, and select "SFTP - SSH File Transfer Protocol". For the host, enter "sftp.distds.com". For the port, enter 22. The "Normal" logon type will work for us, and enter the user name and password given to you by DDS. Click "Connect".

FileZilla will then ask you if you want to save passwords. You should follow your company policies with regard to this. If you select "Save passwords", FileZilla will save your passwords, this being the least secure but most convenient option. If you select "Do not save passwords", the password will not be saved between sessions, and you will need to re-enter it when you reconnect. If you select "Save passwords protected by a master password", all passwords entered into FileZilla will be saved, but to use them, you will need to enter a master password. This would enable you to protect the password provided by DDS with one of your own.

As part of the secure connection process, the server will provide a key to prove its identity. If the key fingerprints match the following, you should click "Always trust this host", then "OK".

At this point, you will have a connection to our SFTP server. You should drop files for us in the folder to-dds, and we will provide files to you in the folder from-dds.

Future connections can be made by opening the Connection Manager again, selecting the DDS connection, then clicking "Connect".
